The 2019 South China International Industrial Automation Exhibition was grandly opened at the Shenzhen Convention and Exhibition Center on June 26. Over 500 leading domestic and foreign brands from 13 countries and regions including Germany, Japan, South Korea, Canada, the United States, Switzerland, Singapore, Italy, Taiwan, and Hong Kong gathered in industrial robots, control systems and transmission technology, automation equipment And electronic manufacturing technology, machine vision, industrial Internet of Things, AGV and other six major sectors jointly interpret the international cutting-edge automation product technology and industry solutions to create an authoritative event in South China's automation field.

UTECH exhibition site

        1. Disordered crawling

The product adopts a combination of industrial manipulator and 3D industrial machine vision inspection system. The 3D industrial machine vision inspection system can assist industrial robots to achieve 3D intelligent grasping. Professionally designed for scattered and disordered and stacked workpieces. High-speed scanning to form high-precision three-dimensional point cloud data, combined with image processing, point cloud analysis, intelligent matching, autonomous motion path planning and anti-collision design, to achieve precise robot positioning and guidance, so that industrial robots have true stereo vision Perception function.

2. Glue the sole

The product adopts a combination of industrial manipulator and 3D industrial machine vision detection system. 3D industrial machine vision technology extracts sole edge data and automatically generates glue trajectories. It is easy to operate and convenient to change lines. Through the motion control to guide the dynamic tracking of the robot arm, the robot can meet the sub-millimeter glue application precision, and realize the flexible operation of the shoe sole glue application.

UTECH Products

1. Micro laser 3D machine vision module

The micro laser 3D machine vision module consists of a single-axis infrared laser scanning module, a micro high-speed binocular stereo camera module and drive control software. The three-dimensional structure of the object is scanned using the coded grating structured light scheme, and the high-precision three-dimensional point cloud information is obtained through the binocular camera module shooting process to reconstruct the three-dimensional structure of the object.

Product features: The laser 3D machine vision module has fast modeling speed, high accuracy, small size, light weight, flexible and convenient installation, and easy integration. It can be widely used in consumer fields such as face recognition, medical and aesthetic plastic surgery, and security.

2. DLP-3D machine vision module

Three anti-DLP-3D machine vision module is composed of white light DLP scanning module, high-speed binocular stereo camera and drive control software. The three-dimensional structure of the object is scanned using the coded grating structured light scheme, and high-precision three-dimensional point cloud information is obtained through the binocular camera shooting process to reconstruct the three-dimensional structure of the object.

Product features: The three-proof DLP-3D machine vision module has an IP65 protection level and is suitable for industrial production environments with complex conditions. Its modeling speed is fast, the Z direction accuracy is 0.2 ~ 0.02mm, the lateral accuracy can reach sub-millimeter level, the optical machine has high brightness, and the working distance can reach 2 meters; it is connected by a Gigabit network cable, which is suitable for long-distance installation and flexible and convenient installation. It can be widely used in the field of machine vision in intelligent production lines such as product inspection on industrial production lines and random grabbing by manipulators.

3. Portable on-site trace extractor

The core part of the portable on-site trace extraction instrument is composed of a micro laser 3D machine vision module and a touch screen industrial control system. Professionally used for the collection and extraction of on-site traces. Using this equipment can achieve the standardization and unification of trace image extraction. The system's unique structured light 3D reconstruction function can maximize the recovery of 3D information left by objects. Through the comparative analysis of 3D information, the efficiency of public security department technicians in detecting cases can be greatly improved.

Application field

        1. Consumer applications

(1) Mainly used in 3D face scanning and recognition electronic products, focusing on mobile phones, smart door locks and other categories.

(2) Medical beauty

2. Application in industry

(1) Robot 3D visual guidance, disorderly grabbing

(2) 3D visual guidance for depalletizing and palletizing

(3) 3D vision guide glue application

(4) 3D inspection

It can do 3D inspection of shape, volume, space angle, etc. In the inspection link of the enterprise, some special-shaped parts cannot be measured with traditional measurement tools. 3D scanning inspection is one of the most effective tools.

3. Application in the field of public security criminal investigation

In the field of security, the extraction and identification of traces has always been an important issue in the field of public security, especially criminal investigation. The high-precision 3D trace extraction device developed by Xiaoyou Intelligent Technology has the characteristics of portable and electronic storage. It can quickly retain traces of criminal investigation scenes. Later, a long-term accumulation of large amounts of data forms a huge database for deep learning and becomes a strong expert in trace A powerful auxiliary tool can effectively improve the detection rate of criminal investigation cases. At this stage, UTECH Intelligent Technology's high-precision 3D trace extraction instrument project has been successfully established as a major project of the Ministry of Public Security, and is the Ministry of Public Security's exclusive solution provider in criminal investigation

UTECH Intelligent Technology, looking forward to cooperating with you! !
